Compact Amplifiers

 Suitable for DOCSIS 3.1  Plug and play  Automatic leveling  2-pilot control  Forward path up to 1218 MHz  Return path up to 204 MHz  2 active power amplifiers  DOCSIS, HMS, FSK monitoring  Electronic setting via WLAN module
VGP 3243D-1G2
VGP 9243D-1G2
Trunk / distribution network amplifiers
 2nd generation GaN power amplifiers  Flexible gain adjustment for trunk / distribution network
 GaN power amplifiers  Gain for trunk / distribution network 37 / 43 dB
VGP 9143D-1G2
VGP 9343D-1G2
 GaN power amplifiers  Gain for distribution network 2 x 43 dB
 GaN power amplifiers  Gain for trunk / distribution network 35 / 43 dB
 Suitable for DOCSIS 3.1  Plug and play  Automatic leveling  2-pilot control (optional with VGX)  Forward path up to 1218 MHz  Return path up to 204 MHz  An active amplifier  Electronic setting via WLAN module
VGP 2143D-1G2
VGP 9043D-1G2
Distribution amplifiers
 2nd generation GaN power amplifiers  DOCSIS, HMS, FSK monitoring
 GaN power amplifiers  DOCSIS, HMS, FSK monitoring
VGX 2143D-1G2
VGX 242D-1G2
 2nd Generation GaN Power Amplifier  Loop-Through Output  FSK Monitoring
 GaN power amplifiers  FSK monitoring
 Exactly reproducible settings  Adjustment via slide switch  Fixed diplex filters  Forward path 85 to 1006 MHz  Return path 5 to 65 MHz  An active amplifier  Loop through output  DOCSIS, HMS monitoring
VGO 939-1G
Distribution amplifiers
 Remote supply via inputs and outputs
 Local supply 230 VAC
VGE 1285-1G2
VGE 12258-1G2
 Gain 12 dB / 10 dB at an angle  Return path 5 to 65 MHz
 Gain 12.5 dB / 11 dB slope  Return path 5 to 204 MHz
 Suitable for DOCSIS 3.1  Forward path up to 1218 MHz  Return to 204 MHz - passive  Remote supply via input / output
Active equalizers
VOS 952-1G
VOS 953-1G
 Exact setting via slide switch  Local supply 230 VAC  DOCSIS, HMS, FSK monitoring
 Self-supply with remote supply voltage  DOCSIS HMS, FSK monitoring
 Forward path up to 1006 MHz  Return to 65 MHz  One active power amplifier
House connection amplifier
