Network Management
NECE & ECE-FA
Ethernet Element Controller for all platforms
•
100BASE-T Ethernet connector
•
Web GUI
•
USB device port for local management
•
General purpose I/O connectors with at least 5 I/O ports
•
LED module status display
•
Supports IPv4
•
Management interfaces: HTTP, SNMP
•
SNMPv1 and v2 support
•
Automatic detection, monitoring and control of all BK or
2G6 modules via the RS485 serial bus
•
Firmware update of connected network elements
•
Backup of the network element configurations
•
Event log (Alarms / Events)
•
Monitoring and configuration of connected network
elements
•
Embedded version for 19 '' rack stand-alone devices
available
NECxE
Gigabit Ethernet Element Controller
Network Element Management
CABLEWatch
•
Web Client - Server Application to manage BKtel HFC,
RFoG and RF Overlay Networks
•
Possibility to connect the network elements via
SNMPv1-3, HTTPs and HMS
•
Visualisation of the entire network
- By network location tree view – hierarchy viewer
- By network location map view – topology viewer
- By network element controller – remote inventory view
•
Network element support
- Supports all BKtel network element controllers with
automatic type recognition
- Remote controlling and firmware upgrade
- Simplified On-Site registration process
- HMS compliant network elements of other vendors can
be integrated on demand
•
Alarm management
- Alarm log view – displays the active events of the
network as a table view
- Alarm statistic – offers the possibility to identify the
problematic network elements
- Alarm notification – delivers alarm notifications via
email
- Double Northbound Interface with customizable
individual filters
•
Architectural base
- Client is OS/Platform independent and runs in a web
browser
- Server is OS/Platform independent (supports Linux
and Windows)
- Automatic full and incremental backups
CABLEwatch Netzwerk Topologie
Client GUI
•
Web browser management and SNMP management
•
Usage in outdoor fiber nodes and in hub/headend
locations
•
Eight RJ45 connectors for 10/100/1000 Mbit/s Ethernet
supporting SNMP and embedded webserver
•
RS485 on rear connector to poll slave units via BK
chassis bus
•
Two SFP (smal form factor pluggable) standard cages for
1GbE SFP transceivers
•
GPIO port with 5 GPIO interfaces
•
USB device interface for local device management via
web browser (RNDIS) access
•
USB host interface
•
LED module status indicator
•
LCD 128 x 128 RGB display and 5-way joystick for
manual (local) control
•
BK mechanics with module width 1 and BK compliant
powering
•
Webserver for HTTP and HTTPS remote access
management interface
•
TLS 1.2 Security Enging
•
Web interface GUI for mobile devices
•
IPv4 support and IPv6 support
•
SNMP support v1, v2, v3
•
Event log (history of alamrs/warnings/events)
•
Advanced user management
•
Limits of parameters for alarms/warning message
generation
•
Display of graphical rackview
