Technical data on request

• Suitable for DOCSIS 3.1 • Plug and play • Automatic leveling • Full redundancy in forward and return • Electronic matrix in the forward and return path • 2-pilot control • Forward path up to 1218 MHz • Return to 204 MHz • 2 active power stages in the forward path • Integrated fiber and component storage • External ingress measuring sockets • Plug-in diplex filter • DOCSIS, HMS, FSK monitoring • Electronic setting via WLAN module

ORA 9222-1G2-B 2nd Generation

• 2 x 2 nodes (2 forward path and 2 return path segments) • Internal optical interfaces for outdoor use (IP67 possible) • 4 high level outputs

• Future-proof digital nodes for network upgrades • DOCSIS 4.0 FDD ready. RF circuits are designed for 1.8 GHz in the forward path and up to 684 MHz in the return path • Pluggable Remote PHY module options: 1x1, 1x2 or 2x2 • Analog overlay option available • Prepared for future Remote MACPHY modules

ORP42x2-1G8
