FTTx and
RFoG Media Converter
RFoG-Node XON65.BFN
•
DOCSIS 3.1 compliant RFoG node: CATV receiver with
1218 MHz and optical return transmitter with 204 MHz
bandwidth
•
The RFoG node complies with the ANSI / SCTE 174
RFoG (RF
•
over Glass) specification and the IEC 60728-14 RFoG
standard
•
Bidirectional node management and remote
configuration
Contact us
Do you have questions
and would you like a
personal consultation?
Do not miss
any news!
Sign-in for our
newsletter.
Fiber Termination Unit XON30.W
•
Basic installation unit for BKTEL CPE product
portfolio
•
Fiber termination for up to 6 bending loss insensitive
fibers (G.657A)
•
Up to 2 additional simplex SC adaptors or 2 duplex
LC adapters on the bottom side
•
Bottom / top / rear access for fiber breakout cables
•
Usage of different splice holders is possible
•
Installation of a gas-blocker with a max diameter of
10 mm
•
Sealing possibility
•
Fixation with up to 4 screws
•
3 universal LED openings
•
Attractive design for living room installations
XON1300 - 4 Port Managed Gigabit
Ethernet Switch
•
1000Base BX optical fiber WAN interface (o ptional
2500Base BX)
•
Fully compliant with IEEE802.3/IEEE802.3z standard
•
I EEE 802.3/802.3u Auto negotiation ability to select
10Base T/100Base TX/1000Base T mode and half/full
duplex
•
L2 wire speed packet switching
•
Jumbo Frame support
•
Virtual LAN support (Port Based and 802.1q VLAN)
•
VLAN Stacking (QinQ IEEE 802.1ad)
•
EEE (Energy Efficient Ethernet) Link On Cable Length
Power Saving: Copper link power adjustment based on
cable length auto detection
•
TR 069 provisioning TR 181/2 data model
•
Auto Provisioning
•
Secure Software Update
•
Dying Gasp
XON4000 - 10 Gigabit Ethernet Media
Converter
•
Optical fiber WAN interface supporting 10GBASE-X
•
Fully compliant with IEEE802.3/IEEE802.3z standard
•
IEEE 802.3/802.3u Auto-negotiation ability to select
1000Base-T/2500Base-TX/5000Base-T/10GBase-T
mode and half/full-duplex
•
Auto-crossover MDI/MDIX feature for plug-and-play
•
Jumbo Frame support
•
EEE (Energy Efficient Ethernet) Link-On Cable
Length Power Saving:
Copper link power adjustment based on cable length
auto-detection LED indication:
Device Status, WAN Status
Optional optical CATV Receiver
•
Optical home receiver for multichannel television and
radio signals like AM-VSB, FM and QAM
•
Bandwidth up to 2400 MHz
•
Ultra low noise push-pull technology
•
Very low distortion
XON3200 - XGS-PON Media Converter
•
Optical fiber WAN interface supporting XGS-PON
•
Fully compliant with ITU-T G.9807.1 XGS-PON
standards
•
Compliant with ITU-T G.9807 Class N1
•
Compliant with ITU-T G.988
•
IEEE 802.3/802.3u Auto-negotiation ability to select
1000Base-T/2500Base-TX/5000Base-T/10GBase-T
mode and half/full-duplex
•
Auto-crossover MDI/MDIX feature for plug-and-play
•
Jumbo Frame support
•
EEE (Energy Efficient Ethernet) Link-On Cable
Length Power Saving:
Copper link power adjustment based on cable length
auto-detection LED indication:
Device Status, WAN Status
Optional optical CATV Receiver
•
Optical home receiver for multichannel television and
radio signals like AM-VSB, FM and QAM
•
Bandwidth up to 2400 MHz
•
Ultra low noise push-pull technology
•
Very low distortion
