Management Software
for Headends
Software option "SNMP monitoring"
The SNMP software extension was developed for the headend
system of the NEO X Series and is a paid software option. This
extension provides an SNMP interface through which all
important status parameters such as module status, fan status,
signal qualities, etc. of a headend system can be monitored.
Properties
•
Provision of an SNMP interface for monitoring a system,
consisting of a base unit (master) and possibly one or more
extensions (slaves)
•
The SNMP agent runs exclusively on the base unit
•
The SNMP agent is configured via SNMP. This includes the
configuration of the access control, the SNMPv3 user and the
notifications
•
Supports all NEO X Series modules except X10-A1
HMT
The HMT software is required to run a NEO X Series, M Series,
or N Series signal processing system and is available for
download free of charge for Windows and Linux.
Properties
•
Centrally control all NEO X Series and NEO M Series
parameters over TCP / IP connection (local or remote)
including cascading, transport stream routing, and enhanced
CI functionality, etc.
•
Control of all NEO N Series parameters via local USB
connection
•
User-friendly interface for easy setup of the wizard
installation
•
(eg NIT / LCN) and tool tips
•
Simplified programming of channel units using channel lists
and configuration templates that can be updated
•
Transferring saved configurations and channel lists to other
installations
